Description
200311_Compressed_AllLabelBrochure_Web
• Quick set-up and easy operation
• Accurately applies pre-printed labels to pouches and bags with variable spacing
• Applies pre-printed labels to pouches quickly and accurately at up to 1,300 labels per hour
• Accepts pouches of different sizes and materials – also works with zippers and degassing valves
• Label liner rewinder
Specification:
| Pouch Width: | 3.2” to 9” (81mm to 229mm) |
| Pouch Height: | 1.75” to 32” (45mm to 812mm) |
| Pouch Thickness: | Up to 0.21” (5.3mm) |
| Supply roll diameter: | Up to 8” (203mm) |
| Media liner width: | 1” to 8.375” (25.4mm to 213mm) |
| Supply roll core: | 2” to 3” I.D. (51.8mm to 76.2mm) |
| Electrical rating: | 12VDC, 5.0A |
| Power requirements: | 100-240 VAC, 50/60 Hz, 60 watts |
| Agency certifications: | UL, UL-C, CE, FCC Class A |
| California Prop 65: |  WARNING: Cancer and Reproductive Toxin – www.p65warnings.ca.gov |
| Weight: | 18.5 lbs. (8.39 kg) |
| Dimensions: | 13.4”W x 7.3”H x 20”D (340mmW x 185mmH x 508mmD) |
| Gap between Labels: | Recommended: 1/8″ – 1/4″ ( 3.175 mm – 6.3500 mm ) |
| Label Type: | Die cut with waste removed. Clear labels can be used. (Labels digitally die-cut on the LX610 are not compatible because the waste is not removed. Learn More.) |
| Label Width: | 0.75” to 8.25” (19mm to 210mm) |
| Label Height: | 0.75” to 32” (19mm to 812mm) |
| Liner Thickness: | 2 mil – 10mil (smoothness will affect feeding – a liner that is too slippery or too thin will slip through the drive rollers) |
| Label + Adhesive Thickness: | 5 mil – 15 mil* |
| Wind Direction | Wound out – See Copy-Position Chart |
